Product Introduction

H8959 provides excellent wireless communication solution to customer by connecting their end devices towards their business success. It has been approved by global customers who are using its cellular based connection solution for all their assets/machines to get online, Wi-Fi station and Ethernet WAN can also be configured to help you build up different network topologies. Plus Links auto-failover, VPN data encryption, and multi-VPN tunnel backup machanism, giving customers a secure and extremely reliable networking solution.

Tech Specs Downloads Ordering

Hardware
CPU	MIPS 24Kc @580 MHz
RAM	128MB
FLASH	16MB
Cellular Interface
Modem	1 x LTE CAT1/CAT4
Number of antennas	2
Connector	SMA-K
SIM	1 x Mini SIM (2FF)
Ethernet Interface
Number of ports	2 x 10/100 Mbps, Ethernet
Configuration	2 x LAN or 1 x LAN + 1 x WAN
PoE output	N/A
Wireless interface
Standards	802.11b/g/n, AP or station mode
Frequency bands	2.4 GHz
Speed	150Mbps
Security	WEP, WPA, WPA2
Encryption	64/128 AES, TKIP
Antennas	1
Connector	RPSMA-K
GNSS interface
Number of antennas	N/A
Connector
Dead Reckoning
Seiral interface
Type	N/A
Socket form
Signal definition
Baudrate
Software
Auto fail-over	Between: Cellular and WAN Cellular and Wi-Fi (station mode) WAN and Wi-Fi (station mode)
Network protocols	PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc.
Network	APN, VPDN, VLAN, QoS
Routing	Static Routing, Policy routing, RIP, OSPF and BGP, etc.
Firewall	NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List
VPN	PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard
Ipsec Encryption	DES, 3DES, AES128, AES192, AES256
OpenVPN Encryption	BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC, SEED-CBC
Remote Management	HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform, SDLAN
Serial ports function	N/A
Power Supply and Consumption
Power Connector	DC socket
Voltage input	+9V~+12V DC
Power consumption	Idle: 100mA@12V DC Data transceiving: 350mA@12V DC
Others
Reset button	Yes
LED indicators	8 x indicators for Modem, Power, WLAN, Ether, Signal
Hardware watchdog	Yes
Physical Characteristics
Ingress protection	IP30
Housing & Weight	Metal, 300g
Dimension	102.8×98.8×23.4(mm)
Installations	Desktop, wall mounting
Operating temperature	-30 ~ +75℃
Storage temperature	-40 ~ +85 °C
Relative humidity	0~95%(no condensation)
EMC
ESD	EN61000-4-2, level3
RS	EN 61000-4-3, level3
EFT	EN 61000-4-4, level3
CS	EN 61000-4-6, level3
Certifications	CE, FCC,Verizon,Sprint,PTCRB,IC,JATE+MIC,VCCI,RCM
